Auto Beer Cave Convenience Store Display Doors

Automatic Beer Cave Door Series

Anthony has partnered with Horton Automatics®, for our all-new Automatic Beer Cave Door for Walk-In Cooler applications. Our new Automatic Beer Cave Door features a motion sensor on the interior and exterior of the door, allowing for easy two-way traffic, and a newly released Heavy Duty drive train tested to 1,000,000 cycles - the ideal mix of durability and merchandise visibility. Every Anthony Automatic Beer Cave Door also includes a Full-Service Installation by a Horton Certified Dealer - taking the guesswork out of whether your Beer Cave door is installed properly.

The Anthony Auto Beer Cave Door provides merchandisers an ultramodern look in the beer and wine aisle that will make your products visible and easily accessible. Engineered to keep beverages ice-cold and zero condensation on the display.

Temperature:

Normal

Color/Finishes:

Black (Dark Bronze)
Satin Silver (Anodized)

Applications:

Walk-In Cooler Single & Double Door Slider

Certifications:

Sizes Available:

Single Door Configurations

Right or Left Handed Slider

Door Size	Slide Opening	Net Opening Width	Net Opening Height	Anthony Anti-sweat Condensation Amps*	Energy Consumption (KWH/DAY)
7’ W x 91” H	2’ - 11 3/4"	84.5”	91.25”	1.85	2.96
8’ W x 91” H	3’ - 5 3/4"	96.5”	91.25"	2.0	3.26
9’ W x 91” H	3’ - 11 3/4"	108.5"	91.25"	2.10	3.58

*20 amp service (in conduit) routed to header. Max current draw is 3.15 Drive Train + Anti-sweat Amps listed above.

Two Door Configurations

Double Door Sliders

Door Size	Unit Width	Slide Opening	Net Opening Width	Net Opening Height	Anthony Anti-sweat Condensation Amps*	Energy Consumption (KWH/DAY)
9’ W x 91” H	9'	3’ - 7 3/8”	108.5”	91.25”	2.61	4.40
10’ W x 91” H	10’	4’ - 1 3/8”	120.5”	91.25"	2.74	4.68
12’ W x 91” H	12’	5’ - 1 3/8”	144.5"	91.25"	3.00	5.32

*20 amp service (in conduit) routed to header. Max current draw is 3.15 Drive Train + Anti-sweat Amps listed above.

Standard Features:

DOE Listing & ETL Listed for Safety
Single Door Sizes: 7’ W x 91” T, 8’ W x 91” T, 9’ W x 91” T
Double Door Sizes: 9’ W x 91” T, 10’ W x 91” T, 12’ W x 91” T
Heavy Duty Drive Train Tested to 1,000,000 Cycles
Attractive 4.5”x 7” Header with attached Motion Sensors at Interior and Exterior for Two-Way Traffic
Three-Pane Non-Heated Low-E Glass with Argon Gas
Door & Frame Rail Heat for 75°F, 55%RH ambient/35°F Walk-In Anti-Condensate Sweat Protection
Anthony Energy Controller Pre-Wired to Frame
Industrial Grade Cylinder Lock with Internal Thumb Lock
Easily Adjustable Opening & Closing Speeds
Manual Operation Mode in Case of Power Failure
Header Mounted Fail Safe/Bypass Switch
Surface Mounted Fail Safe/Bypass Switch
(field installed at customer discretion)
